The Trek Session 9 is a thoroughbred downhill mountain bike with a robust aluminum frame and a chassis design with a high pivot point, which guarantees full suspension performance, better traction and more speed even on the toughest runs. It's based on our best DH suspension package, a powerful drivetrain and powerful Code RSC brakes.
Highlights:
- Frame: Alpha Platinum Aluminum, high main pivot
- Suspension fork: RockShox BoXXer Ultimate, DebonAir spring, Charger 2.1, 200mm travel
- Shock: RockShox Super Deluxe Ultimate DH 200mm
- Rear derailleur: SRAM X01 DH 7 gears
- Brakes: Sram Code RSC 220/200mm
- Wheels: Bontrager Line DH 30
- Tires: Bontrager G5 Team Issue 2.5 inch DH
- Weight according to the manufacturer: approx. 17.70 kg
"All specifications can be found under additional information."
Frame sizes:
M=R1 161-175cm
L=R2 174-188cm
XL = R3 186-196cm
IMPORTANT NOTE: Due to the currently very difficult availability of bicycle components on the market, the bicycle manufacturers reserve the right to exchange components for equivalent ones. This measure allows delivery dates to be met and the availability of the bikes to be secured. We therefore ask for your understanding if small deviations from the specified specifications can occur. (Translated with Google Translate)
Highlights:
- Frame: Alpha Platinum Aluminum, high main pivot
- Suspension fork: RockShox BoXXer Ultimate, DebonAir spring, Charger 2.1, 200mm travel
- Shock: RockShox Super Deluxe Ultimate DH 200mm
- Rear derailleur: SRAM X01 DH 7 gears
- Brakes: Sram Code RSC 220/200mm
- Wheels: Bontrager Line DH 30
- Tires: Bontrager G5 Team Issue 2.5 inch DH
- Weight according to the manufacturer: approx. 17.70 kg
"All specifications can be found under additional information."
Frame sizes:
M=R1 161-175cm
L=R2 174-188cm
XL = R3 186-196cm
IMPORTANT NOTE: Due to the currently very difficult availability of bicycle components on the market, the bicycle manufacturers reserve the right to exchange components for equivalent ones. This measure allows delivery dates to be met and the availability of the bikes to be secured. We therefore ask for your understanding if small deviations from the specified specifications can occur. (Translated with Google Translate)
| A Seat tube | Keine Angabe |
| B Top tube horizontal | Keine Angabe |
| C Seat tube angle | Keine Angabe |
| D Head tube angle | Keine Angabe |
| E Chain stay | Keine Angabe |
| F Chainstays travel | Keine Angabe |
| G Head tube | Keine Angabe |
| H Wheel base | Keine Angabe |
| I Distance bottom bracket to hub axle | Keine Angabe |
| J Reach | Keine Angabe |
| K Stack | Keine Angabe |
| SportOkay.com number | 0362-10093 |
|---|---|
| GTIN | 601842864715 |
| Item number | 5279092 (R1) |
| Brand | Trek |
| Gender | Male, Unisex |
| Material | Aluminium |
| Product type | Full suspension |
| Area of use | Downhill |
| Speed | 7-speed |
| Shock travel | 200 |
| Brake disk size | 220/200 |
| Gears | 7 |
| Wheel size | 29 |
| Fork travel | 200 |
| Frame | Alpha Platinum Aluminium, hoher Hauptdrehpunkt, Umlenkrolle, integrierter Rahmenschutz, interne oder externe Zugverlegung, Magnesiumumlenkhebel, Mino Link, ISCG 05 2-LochAufnahme, Active Braking Pivot |
| Fork | RockShox BoXXer Ultimate, DebonAir-Feder, Charger 2 RC2-Dämpfung, gerader Gabelschaft, 46 mm Vorbiegung, Boost, 110 x 20 mm Maxle Stealth-Achse, 200 mm Federweg |
| Bike colour | Team |
| Shock | RockShox Super Deluxe Ultimate DH RC2, 250 x 72,5 mm / 200mm Federweg |
| Headset | FSA Orbit, gedichtetes Patronenlager, 1 1/8" oben, 1,5" unten (einschließlich angeschrägter Schalen zur Geometrieverstellung) |
| Stem | Bontrager Line Pro, 35 mm, Direct Mount, 50 mm Länge |
| Handlebar | Bontrager Line Pro, OCLV Carbon, 35 mm, 27,5 mm Rise, 820 mm Breite |
| Grips | Bontrager XR Trail Elite, Nylonklemme |
| Rear Derailleur | SRAM X01 DH, mittlerer Käfig |
| Cassette | SRAM PG-720, 11-25, 7fach |
| chain | SRAM PC-1110 |
| Trigger shifter | SRAM X01 DH, 7fach |
| Brake system | SRAM Code RSC, 4 Kolben hydraulische Scheibenbremse |
| Crankset | SRAM X01 DH, DUB 83, Aluminiumkettenblatt (34 Z.), 165 mm Kurbelarmlänge |
| Wheel set | Bontrager Line DH 30, Tubeless Ready, 6-bolt, 110x20mm Boost thru axle |
| Front tire | Bontrager G5 Team Issue, Drahtwulstkern, doppellagig, 60 TPI, 29 x 2.50 |
| Rear tire | Bontrager G5 Team Issue, Drahtwulstkern, doppellagig, 60 TPI, 29 x 2.50 |
| Seat | Bontrager Arvada, Austenitstreben, 138 mm Breite |
| Seat post | Bontrager Rhythm Elite, 31,6 mm, 0 mm Versatz, 330 mm Länge |
| Pedals | Im Lieferumfang enthalten. / Included. / Inclusi: Wellgo MG-1, Magnesiumkörper, CrMo-Achse, austauschbare Pins |
